Xerox Phaser 6128MFP Service Manual

Phaser 6128MFP Service Manual 3-33
Error Messages and Codes
Fuser Fuser Error
Error 010-397
Error Code:xx
Restart Printer
<IOT Fuser Failure>
Fuser failure is detected.
■ 01: NC circuit fail
■ 02: NC Detect disconnection
■ 03: NC Detect fail
■ 04: NC Comp disconnection
■ 05: NC Comp fail
■ 06: NC Temp Over
■ 07: STS Temp Over
■ 08: NC Comp Table Fail
■ 09: NC Overheat
■ 0A: STS disconnection
■ 0B: STS Overheat
■ 0C: STS Low-temp
■ 0D: NC Low-temp
■ 0E: Cool Time-over
■ 0F: Fuser Ready Time-over ER1
■ 10: NC Warm-up Time-over ER2
■ 11: Fuser Ready Time-over ER2
■ 12: Relay Off STS H
■ 13: Relay Off NC H
■ 14: Relay Other
■ 15: Fuser Machine Code ERR
■ 16: Fuser Ready Timeover ER3
■ NC: No Contact Sensor
■ STS: Soft Touch Sensor
page 3-55
Fuser 010-317
Reseat Fuser
Restart Printer
<IOT Fuser Detached>
Fuser is disconnected.
page 3-56
Fuser Copy, Scan, Fax, Fuser
Life
<IOT Fuser Life Pre Warning>
Fuser is near end of life.
page 3-54
ADF Jam at Scanner
Open ADF Cover R
and remove paper
Turn the Green Dial to
remove paper or
return the removed
original and Press
Start
<PICKUP JAM>
The Pick Up jam occurred.
page 3-53
ADF Jam at Scanner
Open ADF Cover R
and remove paper
Turn the Green Dial to
remove paper or
return the removed
original and Press
Start
<ADF JAM>
The ADF jam occurred.
page 3-53
ADF Job was Finished
005-124
Open ADF Cover and
Remove Document
<ADF Jam>
The ADF Jam occurred when
the job was cancelled.
page 3-53
ADF Scanner ADF Cover R
Open
Close ADF Cover
<ADF Cover Open>
The ADF Cover is open.
page 3-108
Error Message Summary (continued)
System Error Message Error Type Go to

Xerox Phaser 6128MFP Specifications

General

Print technology	Laser
Maximum resolution	600 x 600 DPI
Economical printing	Yes
Time to first page (black, normal)	14 s
Time to first page (color, normal)	17 s
Print speed (black, normal quality, A4/US Letter)	16 ppm
Print speed (color, normal quality, A4/US Letter)	12 ppm
Scanner type	Flatbed scanner
Image formats supported	JPG, TIF
Copier resize	- %
Time to first copy (black, normal)	18 s
Copy speed (black, normal quality, A4)	16 cpm
Copy speed (color, normal quality, A4)	12 cpm
Faxing	Mono faxing
Fax speed dialing (max numbers)	200
Total input capacity	250 sheets
Total output capacity	150 sheets
Display	LCD
Market positioning	Business
Internal memory	384 MB
Card reader integrated	No
Sound pressure level (copying)	52.2 dB
Sound pressure level (printing)	14.9 dB
Maximum print size	216 x 297 mm
Paper tray media types	Bond paper, Card stock, Envelopes, Glossy paper, Labels, Plain paper
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Legal (media size), Letter (media size), Oficio (media size), Statement (140 x 216mm)
ISO A-series sizes (A0...A9)	A4, A5
JIS B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 216 g/m²
Power supply type	AC
Dimensions (WxDxH)	425 x 507 x 585 mm
Power requirements	120 V, 50/60 Hz
Networking features	Fast Ethernet
All-in-one functions	Copy, Fax, Scan
Standard media sizes	76.2 x 127 mm - 215.6 x 355.6 mm
Color all-in-one functions	copy, print, scan
Compatible operating systems	Windows 2000+ Mac OS X v10.3 - 10.5 Red Hat Enterprise Linux 5 Desktop SUSE Linux Desktop 10+
Dimensions (W x D x H) (imperial)	16.7 x 20 x 23 \
Acoustic power emissions (active, print, copy or scan)	62.2/30.3 dB
Standard interfaces	USB 2.0
USB 2.0 ports quantity	1
Power consumption (standby)	18.4 W
Power consumption (average operating)	360 W
Sustainability certificates	ENERGY STAR
Certification	EEC, FCC
Maximum duty cycle	40000 pages per month
Recommended duty cycle	3000 pages per month
Storage temperature (T-T)	-20 - 40 °C
Operating temperature (T-T)	10 - 32 °C
Non-operating relative humidity (non-condensing)	10 - 85 %
