Xerox Phaser 6128MFP Service Manual

3-32 Phaser 6128MFP Service Manual
Error Messages and Codes
Belt CTD Sensor Error
Error 092-310
Error Code:000000xx
Restart Printer
<IOT CTD (ADC) Sensor Error>
CTD sensor error detected.
01 or 10: Y Toner Patch Error
02 or 20: M Toner Patch Error
03 or 30: Y and M Toner Error
04 or 40: C Toner Patch Error
05 or 50: Y and C Toner Error
06 or 60: M and C Toner Error
07 or 70: Y, M, C Toner Error
08 or 80: K Toner Patch Error
09 or 90: Y and K toner Error
0A or A0: M and K Toner Error
0B or B0: Y, M, K Toner Error
0C or C0: C, K Toner Error
0D or D0: Y, C, K Toner Error
0E or E0: M, C, K Toner Error
0F or F0: Y, M, C, K Toner Error
page 3-109
Belt Copy, Scan, Fax, CTD
Sensor
<IOT CTD (ADC) Sensor
Contamination>
Dusty CTD Sensor detected.
page 3-111
Belt Check Unit
CTD Sensor
<IOT CTD (ADC) Sensor
Contamination>
Dusty CTD Sensor detected.
page 3-111
Belt Copy, Scan, Fax, CTD
Sensor
<IOT Transfer Assy Life Pre
Warning>
Transfer Belt near end of life.
page 3-111
Belt DTB Life Over
Error 094-351
Restart Printerr
<IOT Transfer Assy Life Over>
Transfer Belt at end of life.
page 3-111
Motor Motor Error
Error 042-325
Restart Printer
<IOT Motor Failure>
Main Motor failure detected.
page 3-100
Motor Motor Error
Error 042-326
Restart Printer
<IOT Motor Failure>
Sub Motor failure detected.
page 3-102
Motor Fan Motor Error
Error 042-328
Restart Printer
<IOT Fan Motor Failure>
Fan Motor failure detected.
page 3-103
Fuser Replace Fuser
010-351 Printer
Replace Fuser
<IOT Fuser Life Over>
Fuser has reached end of life.
page 3-54
Error Message Summary (continued)
System Error Message Error Type Go to

Xerox Phaser 6128MFP Specifications

General

Print technology	Laser
Maximum resolution	600 x 600 DPI
Economical printing	Yes
Time to first page (black, normal)	14 s
Time to first page (color, normal)	17 s
Print speed (black, normal quality, A4/US Letter)	16 ppm
Print speed (color, normal quality, A4/US Letter)	12 ppm
Scanner type	Flatbed scanner
Image formats supported	JPG, TIF
Copier resize	- %
Time to first copy (black, normal)	18 s
Copy speed (black, normal quality, A4)	16 cpm
Copy speed (color, normal quality, A4)	12 cpm
Faxing	Mono faxing
Fax speed dialing (max numbers)	200
Total input capacity	250 sheets
Total output capacity	150 sheets
Display	LCD
Market positioning	Business
Internal memory	384 MB
Card reader integrated	No
Sound pressure level (copying)	52.2 dB
Sound pressure level (printing)	14.9 dB
Maximum print size	216 x 297 mm
Paper tray media types	Bond paper, Card stock, Envelopes, Glossy paper, Labels, Plain paper
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Legal (media size), Letter (media size), Oficio (media size), Statement (140 x 216mm)
ISO A-series sizes (A0...A9)	A4, A5
JIS B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 216 g/m²
Power supply type	AC
Dimensions (WxDxH)	425 x 507 x 585 mm
Power requirements	120 V, 50/60 Hz
Networking features	Fast Ethernet
All-in-one functions	Copy, Fax, Scan
Standard media sizes	76.2 x 127 mm - 215.6 x 355.6 mm
Color all-in-one functions	copy, print, scan
Compatible operating systems	Windows 2000+ Mac OS X v10.3 - 10.5 Red Hat Enterprise Linux 5 Desktop SUSE Linux Desktop 10+
Dimensions (W x D x H) (imperial)	16.7 x 20 x 23 \
Acoustic power emissions (active, print, copy or scan)	62.2/30.3 dB
Standard interfaces	USB 2.0
USB 2.0 ports quantity	1
Power consumption (standby)	18.4 W
Power consumption (average operating)	360 W
Sustainability certificates	ENERGY STAR
Certification	EEC, FCC
Maximum duty cycle	40000 pages per month
Recommended duty cycle	3000 pages per month
Storage temperature (T-T)	-20 - 40 °C
Operating temperature (T-T)	10 - 32 °C
Non-operating relative humidity (non-condensing)	10 - 85 %
