Xerox Phaser 6128MFP Service Manual

Phaser 6128MFP Service Manual 3-31
Error Messages and Codes
Jam Reseat paper from
Manual Feed
<IOT SSF Paper Staying>
Feeding from Tray fails due to
a sheet remaining in the
manual feed slot.
page 3-83
Jam Jam at Front Cover
Open Front Cover and
Remove Paper
<IOT Regi Jam>
Media reached the
Registration Sensor earlier
than expected.
page 3-43
Jam Jam at Front Cover
Open Front Cover and
Remove Paper
<IOT Regi Jam>
Media does not pass through
the Registration Sensor on
time.
page 3-43
Jam Jam at Exit
Open Front Cover and
Remove Paper
<IOT Regi Jam>
Media does not reach the
Registration Sensor as
expected.
page 3-37
Jam Jam at Exit
Open Front Cover and
Remove Paper
<IOT Exit Jam>
Media reached the Exit Sensor
earlier than expected.
page 3-45
Jam Jam at Exit
Open Front Cover and
Remove Paper
<IOT Exit Jam>
Media does not pass through
the Exit Sensor on time.
page 3-45
Jam Jam at Exit
Open Front Cover
<IOT Remain Exit JAM>
Media remains at Exit Sensor.
page 3-45
Jam Jam at Reg. Roll
Open Front Cover
<IOT Remain Regi JAM>
Media remains at Registration
Sensor.
page 3-50
Media Load Tray
XXX(Paper Size)
Load Tray
YYY(Paper Type)
<IOT Paper Size Mismatch in
Tray 1>
Paper size mismatch for Tray
detected.
page 3-73
Media Load Manual Feed
XXX(Paper Size)
Load Manual Feed
YYY(Paper Type)
<IOT Paper Size Mismatch in
SSF>
Paper size mismatch for
manual feed slot detected.
page 3-73
Media Load Tray
XXX(Paper Size)
Load Tray
YYY(Paper Type)
<No suitable paper in Tray 1>
No media in Tray.
page 3-75
Media Load Manual Feed
XXX(Paper Size)
Load Manual Feed
YYY(Paper Type)
<No suitable paper in SSF>
No media in manual feed slot.
page 3-81
Media Press OK Button to
continue
<No suitable paper in SSF>
No media in manual feed slot.
page 3-81
Error Message Summary (continued)
System Error Message Error Type Go to

Xerox Phaser 6128MFP Specifications

General

Print technology	Laser
Maximum resolution	600 x 600 DPI
Economical printing	Yes
Time to first page (black, normal)	14 s
Time to first page (color, normal)	17 s
Print speed (black, normal quality, A4/US Letter)	16 ppm
Print speed (color, normal quality, A4/US Letter)	12 ppm
Scanner type	Flatbed scanner
Image formats supported	JPG, TIF
Copier resize	- %
Time to first copy (black, normal)	18 s
Copy speed (black, normal quality, A4)	16 cpm
Copy speed (color, normal quality, A4)	12 cpm
Faxing	Mono faxing
Fax speed dialing (max numbers)	200
Total input capacity	250 sheets
Total output capacity	150 sheets
Display	LCD
Market positioning	Business
Internal memory	384 MB
Card reader integrated	No
Sound pressure level (copying)	52.2 dB
Sound pressure level (printing)	14.9 dB
Maximum print size	216 x 297 mm
Paper tray media types	Bond paper, Card stock, Envelopes, Glossy paper, Labels, Plain paper
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Legal (media size), Letter (media size), Oficio (media size), Statement (140 x 216mm)
ISO A-series sizes (A0...A9)	A4, A5
JIS B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 216 g/m²
Power supply type	AC
Dimensions (WxDxH)	425 x 507 x 585 mm
Power requirements	120 V, 50/60 Hz
Networking features	Fast Ethernet
All-in-one functions	Copy, Fax, Scan
Standard media sizes	76.2 x 127 mm - 215.6 x 355.6 mm
Color all-in-one functions	copy, print, scan
Compatible operating systems	Windows 2000+ Mac OS X v10.3 - 10.5 Red Hat Enterprise Linux 5 Desktop SUSE Linux Desktop 10+
Dimensions (W x D x H) (imperial)	16.7 x 20 x 23 \
Acoustic power emissions (active, print, copy or scan)	62.2/30.3 dB
Standard interfaces	USB 2.0
USB 2.0 ports quantity	1
Power consumption (standby)	18.4 W
Power consumption (average operating)	360 W
Sustainability certificates	ENERGY STAR
Certification	EEC, FCC
Maximum duty cycle	40000 pages per month
Recommended duty cycle	3000 pages per month
Storage temperature (T-T)	-20 - 40 °C
Operating temperature (T-T)	10 - 32 °C
Non-operating relative humidity (non-condensing)	10 - 85 %
