Xerox Phaser 6128MFP Service Manual

3-110 Phaser 6128MFP Service Manual
Error Messages and Codes
4 Run the Toner Motor test for the
affected color (DO-21, DO-23, DO-
25, DO-27) on (page 4-47).
Does the motor rotate?
Go to step 5. Go to step 6.
5 Check the Dispense Assembly gear
for the indicated color.
Is the gear damaged or excessively
worn?
Repair or
replace the
gear or
Dispense
Assembly
(page 8-91).
Go to step 6.
6 Check MCU Board connectors P/J18
and toner motor connections:
■ P/J181(Y)
■ P/J182(M)
■ P/J191(C)
■ P/J192(K)
Are the connectors secure?
Go to step 7. Reconnect the
connectors.
7 Check Toner Motor harness
continuity. Disconnect P/J18 from
the MCU Board and the connection
to the indicated toner motor.
Is the harness damaged?
Repair or
replace the
harness
(PL10.8.7).
Go to step 8.
8 Check for +24 V at J18 or J19 on the
MCU Board.
Is +24 V available at
■ J18-3 (Y)
■ J18-8 (M)
■ J19-4 (C)
■ J19-9 (K)
when the Interlock Switch is closed?
Replace the
Dispense
Assembly
(page 8-91).
Replace the
MCU Board
(page 8-57).
9 Reseat the Imaging Unit.
Does the error persist?
Go to step 10. Complete.
10 Replace the indicated Toner
Cartridge.
Does the error persist?
Replace the
Transfer Belt
(page 8-103).
Complete.
Troubleshooting Procedure Table (continued)
Step Actions and Questions Yes No

Xerox Phaser 6128MFP Specifications

General

Print technology	Laser
Maximum resolution	600 x 600 DPI
Economical printing	Yes
Time to first page (black, normal)	14 s
Time to first page (color, normal)	17 s
Print speed (black, normal quality, A4/US Letter)	16 ppm
Print speed (color, normal quality, A4/US Letter)	12 ppm
Scanner type	Flatbed scanner
Image formats supported	JPG, TIF
Copier resize	- %
Time to first copy (black, normal)	18 s
Copy speed (black, normal quality, A4)	16 cpm
Copy speed (color, normal quality, A4)	12 cpm
Faxing	Mono faxing
Fax speed dialing (max numbers)	200
Total input capacity	250 sheets
Total output capacity	150 sheets
Display	LCD
Market positioning	Business
Internal memory	384 MB
Card reader integrated	No
Sound pressure level (copying)	52.2 dB
Sound pressure level (printing)	14.9 dB
Maximum print size	216 x 297 mm
Paper tray media types	Bond paper, Card stock, Envelopes, Glossy paper, Labels, Plain paper
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Legal (media size), Letter (media size), Oficio (media size), Statement (140 x 216mm)
ISO A-series sizes (A0...A9)	A4, A5
JIS B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 216 g/m²
Power supply type	AC
Dimensions (WxDxH)	425 x 507 x 585 mm
Power requirements	120 V, 50/60 Hz
Networking features	Fast Ethernet
All-in-one functions	Copy, Fax, Scan
Standard media sizes	76.2 x 127 mm - 215.6 x 355.6 mm
Color all-in-one functions	copy, print, scan
Compatible operating systems	Windows 2000+ Mac OS X v10.3 - 10.5 Red Hat Enterprise Linux 5 Desktop SUSE Linux Desktop 10+
Dimensions (W x D x H) (imperial)	16.7 x 20 x 23 \
Acoustic power emissions (active, print, copy or scan)	62.2/30.3 dB
Standard interfaces	USB 2.0
USB 2.0 ports quantity	1
Power consumption (standby)	18.4 W
Power consumption (average operating)	360 W
Sustainability certificates	ENERGY STAR
Certification	EEC, FCC
Maximum duty cycle	40000 pages per month
Recommended duty cycle	3000 pages per month
Storage temperature (T-T)	-20 - 40 °C
Operating temperature (T-T)	10 - 32 °C
Non-operating relative humidity (non-condensing)	10 - 85 %
