Xerox Phaser 6128MFP Service Manual

4-16 Phaser 6128MFP Service Manual
General Troubleshooting
Dial tone Min
(10ms)
Sets the minimum limit of dial tone
pattern detection duration.
Dial tone Max
(10ms)
Sets the maximum limit of dial tone
pattern detection duration.
CNG Stop
Select
Sets the conditions for stopping CNG
transmission. Conditions :
CED&V21: When CED and V.21
preamble are detected.
CED: When CED is detected.
V21: When V.21 preamble is
detected.
G3M TX Cable
EQU
Sets the cable amplitude equalizer
value for transmission. These values
are available:
0db Equal to a cable length of 0km.
4db Equal to a cable length of 1.9km
8db Equal to a cable length of 3.6km
12db Equal to a cable length of
7.2km
G3M RX Cable
EQU
Sets the cable amplitude equalizer
value for reception (applicable to
V17, V29, and V27ter) These values
are available:
0db Equal to a cable length of 0km.
4db Equal to a cable length of 1.9km
8db Equal to a cable length of 3.6km
12db Equal to a cable length of
7.2km
G3M V34 Bit
Rate
Sets the signaling rate for the Super
G3 (V34) mode. Values range from
2400bps to 33600bps in 14 steps.
2400/4800/7200/9600/12000/
14400/16800/19200/21600/24000/
26400/28800/31200/33600
Capability V34 Sets the communication capability
of the Super G3 (V34) mode.
G3M TX
Coding
Sets the data encoding method for
transmission. When the encoding
method set here is not supported by
the receiving side, the receiving
side's method is adopted. Available
methods: are MH/MR/ MMR/JBIG
G3M RX
Coding
Sets the data encoding method for
reception. Available methods: are
MH/MR/ MMR/JBIG
BackUp Data NOTE:
The system data initialization does not initialize data on EEPROM
(except dial types and country codes). The counter clear does not clear
scan counter clearance on EEPROM; it only clears counters on SRAM.
Test Control Panel Display Test Description

Xerox Phaser 6128MFP Specifications

General

Print technology	Laser
Maximum resolution	600 x 600 DPI
Economical printing	Yes
Time to first page (black, normal)	14 s
Time to first page (color, normal)	17 s
Print speed (black, normal quality, A4/US Letter)	16 ppm
Print speed (color, normal quality, A4/US Letter)	12 ppm
Scanner type	Flatbed scanner
Image formats supported	JPG, TIF
Copier resize	- %
Time to first copy (black, normal)	18 s
Copy speed (black, normal quality, A4)	16 cpm
Copy speed (color, normal quality, A4)	12 cpm
Faxing	Mono faxing
Fax speed dialing (max numbers)	200
Total input capacity	250 sheets
Total output capacity	150 sheets
Display	LCD
Market positioning	Business
Internal memory	384 MB
Card reader integrated	No
Sound pressure level (copying)	52.2 dB
Sound pressure level (printing)	14.9 dB
Maximum print size	216 x 297 mm
Paper tray media types	Bond paper, Card stock, Envelopes, Glossy paper, Labels, Plain paper
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Legal (media size), Letter (media size), Oficio (media size), Statement (140 x 216mm)
ISO A-series sizes (A0...A9)	A4, A5
JIS B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 216 g/m²
Power supply type	AC
Dimensions (WxDxH)	425 x 507 x 585 mm
Power requirements	120 V, 50/60 Hz
Networking features	Fast Ethernet
All-in-one functions	Copy, Fax, Scan
Standard media sizes	76.2 x 127 mm - 215.6 x 355.6 mm
Color all-in-one functions	copy, print, scan
Compatible operating systems	Windows 2000+ Mac OS X v10.3 - 10.5 Red Hat Enterprise Linux 5 Desktop SUSE Linux Desktop 10+
Dimensions (W x D x H) (imperial)	16.7 x 20 x 23 \
Acoustic power emissions (active, print, copy or scan)	62.2/30.3 dB
Standard interfaces	USB 2.0
USB 2.0 ports quantity	1
Power consumption (standby)	18.4 W
Power consumption (average operating)	360 W
Sustainability certificates	ENERGY STAR
Certification	EEC, FCC
Maximum duty cycle	40000 pages per month
Recommended duty cycle	3000 pages per month
Storage temperature (T-T)	-20 - 40 °C
Operating temperature (T-T)	10 - 32 °C
Non-operating relative humidity (non-condensing)	10 - 85 %
