Xerox Phaser 6128MFP Service Manual

Phaser 6128MFP Service Manual 4-15
General Troubleshooting
Page Margin 2
(mm)
Sets the page margin that allows a
larger-than-standard size document
to be handled as a standard size
document. The document is reduced
to the standard size, by the set value.
Values range from 0 to 127. When
the value is 10, the margin is 10 mm.
Valid when the Discard Size setting
in Fax Setting is "On"
Extel Hook
Thresh
Sets the threshold of ON HOOK
detection at the external telephone
to one of Lower, Normal, and Higher.
Dis DP 20PPS Sets whether or not to enable 20PPS
dial pulse. When 20PPS is disabled in
this menu, any 20PPS setting in
other menu will be overridden with
10PPS.
CNG Detect
(0.1s)
Sets the CNG detection duration for
telephone-FAX switching. Values
range from 0 to 255. When the value
is 100, the detecting time is 10 sec.
Auto Answer
(1.0s)
Sets the ring tone duration of the
external telephone terminal for FAX-
telephone switching. Values range
from 0 to 255. When the value is
100, the duration is 100 sec.
Num Check
(1.0s)
Sets the autodialing delay duration
when different sets of document
data bound for the same destination
are placed consecutively in the
transmission queue. This pause
allows the receiving side to make
time for processing.
Values range from 1 to 255. When
the value is 10, the pause is 10 sec.
OffHook LCS
Rate (%)
Sets the threshold of off hook
detection at LCS. Values range from
1 to 100.
Dial tone TO
(1.0s)
Sets the time out for detecting the
dial tone. Values range from 0 to
255. When the value is 10, the dial
tone detect duration is 10 sec.
OnHook Detect
(20ms)
Sets the detecting duration for a
valid on hook signal. Values range
from 10 to 255. When the value is
10, the duration is 200 msec. Any on
hook signal shorter than the set time
is invalid.
Dis Dial tone Sets whether or not to enable dial
tone pattern detection.
Test Control Panel Display Test Description

Xerox Phaser 6128MFP Specifications

General

Print technology	Laser
Maximum resolution	600 x 600 DPI
Economical printing	Yes
Time to first page (black, normal)	14 s
Time to first page (color, normal)	17 s
Print speed (black, normal quality, A4/US Letter)	16 ppm
Print speed (color, normal quality, A4/US Letter)	12 ppm
Scanner type	Flatbed scanner
Image formats supported	JPG, TIF
Copier resize	- %
Time to first copy (black, normal)	18 s
Copy speed (black, normal quality, A4)	16 cpm
Copy speed (color, normal quality, A4)	12 cpm
Faxing	Mono faxing
Fax speed dialing (max numbers)	200
Total input capacity	250 sheets
Total output capacity	150 sheets
Display	LCD
Market positioning	Business
Internal memory	384 MB
Card reader integrated	No
Sound pressure level (copying)	52.2 dB
Sound pressure level (printing)	14.9 dB
Maximum print size	216 x 297 mm
Paper tray media types	Bond paper, Card stock, Envelopes, Glossy paper, Labels, Plain paper
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Legal (media size), Letter (media size), Oficio (media size), Statement (140 x 216mm)
ISO A-series sizes (A0...A9)	A4, A5
JIS B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 216 g/m²
Power supply type	AC
Dimensions (WxDxH)	425 x 507 x 585 mm
Power requirements	120 V, 50/60 Hz
Networking features	Fast Ethernet
All-in-one functions	Copy, Fax, Scan
Standard media sizes	76.2 x 127 mm - 215.6 x 355.6 mm
Color all-in-one functions	copy, print, scan
Compatible operating systems	Windows 2000+ Mac OS X v10.3 - 10.5 Red Hat Enterprise Linux 5 Desktop SUSE Linux Desktop 10+
Dimensions (W x D x H) (imperial)	16.7 x 20 x 23 \
Acoustic power emissions (active, print, copy or scan)	62.2/30.3 dB
Standard interfaces	USB 2.0
USB 2.0 ports quantity	1
Power consumption (standby)	18.4 W
Power consumption (average operating)	360 W
Sustainability certificates	ENERGY STAR
Certification	EEC, FCC
Maximum duty cycle	40000 pages per month
Recommended duty cycle	3000 pages per month
Storage temperature (T-T)	-20 - 40 °C
Operating temperature (T-T)	10 - 32 °C
Non-operating relative humidity (non-condensing)	10 - 85 %
