Xerox Phaser 6128MFP Service Manual

4-14 Phaser 6128MFP Service Manual
General Troubleshooting
Parameter Parameter These functions read and write
parameters stored on the Image
Processor Board. Run this to
configure Scanner values manually.
Continue
Illegal
■ Clear - delete data
■ Transmit - contents of
memory.
Specifies how to handle the
document data when the
transmission queue overflows
memory.
Thresh
Memory RX
(%)
Sets the percentage of memory
reserved when data is received.
When the remaining memory
amount falls below this threshold,
data reception is denied. Values
range from 0 to 100. The smaller the
value, the larger data storage
capacity becomes.
Thresh
Immediate
(%)
Sets the remaining memory
threshold that triggers immediate
output. Immediate output refers to
an automatic image output to
accommodate incoming data that
exceeds memory capacity.
Values range from 0 to 99. The larger
the value, the sooner the immediate
output is initiated.
Thresh
Memory TX
(%)
Sets the percentage of memory
reserved when data is sent. Values
range from 0 to 100. The smaller the
value, the greater the available
memory for scanned documents.
Thresh GC (%) Sets the remaining memory amount
in the Flash file system for image
data storage that triggers garbage
collection.
Page Margin 1
(mm)
Sets the page margin that allows a
larger-than-standard size document
to be handled as a standard size
document. The document is reduced
to the standard size by the set value.
Values range from 0 to 127. When
the value is 10, the margin is 10 mm.
Valid when the Discard Size setting
in Fax Setting is "Off"
Test Control Panel Display Test Description

Xerox Phaser 6128MFP Specifications

General

Print technology	Laser
Maximum resolution	600 x 600 DPI
Economical printing	Yes
Time to first page (black, normal)	14 s
Time to first page (color, normal)	17 s
Print speed (black, normal quality, A4/US Letter)	16 ppm
Print speed (color, normal quality, A4/US Letter)	12 ppm
Scanner type	Flatbed scanner
Image formats supported	JPG, TIF
Copier resize	- %
Time to first copy (black, normal)	18 s
Copy speed (black, normal quality, A4)	16 cpm
Copy speed (color, normal quality, A4)	12 cpm
Faxing	Mono faxing
Fax speed dialing (max numbers)	200
Total input capacity	250 sheets
Total output capacity	150 sheets
Display	LCD
Market positioning	Business
Internal memory	384 MB
Card reader integrated	No
Sound pressure level (copying)	52.2 dB
Sound pressure level (printing)	14.9 dB
Maximum print size	216 x 297 mm
Paper tray media types	Bond paper, Card stock, Envelopes, Glossy paper, Labels, Plain paper
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Legal (media size), Letter (media size), Oficio (media size), Statement (140 x 216mm)
ISO A-series sizes (A0...A9)	A4, A5
JIS B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 216 g/m²
Power supply type	AC
Dimensions (WxDxH)	425 x 507 x 585 mm
Power requirements	120 V, 50/60 Hz
Networking features	Fast Ethernet
All-in-one functions	Copy, Fax, Scan
Standard media sizes	76.2 x 127 mm - 215.6 x 355.6 mm
Color all-in-one functions	copy, print, scan
Compatible operating systems	Windows 2000+ Mac OS X v10.3 - 10.5 Red Hat Enterprise Linux 5 Desktop SUSE Linux Desktop 10+
Dimensions (W x D x H) (imperial)	16.7 x 20 x 23 \
Acoustic power emissions (active, print, copy or scan)	62.2/30.3 dB
Standard interfaces	USB 2.0
USB 2.0 ports quantity	1
Power consumption (standby)	18.4 W
Power consumption (average operating)	360 W
Sustainability certificates	ENERGY STAR
Certification	EEC, FCC
Maximum duty cycle	40000 pages per month
Recommended duty cycle	3000 pages per month
Storage temperature (T-T)	-20 - 40 °C
Operating temperature (T-T)	10 - 32 °C
Non-operating relative humidity (non-condensing)	10 - 85 %
