4-34 Phaser 6128MFP Service Manual
General Troubleshooting
5. Press the Stop button to stop the Exit Sensor test.
s6128mfp-074
Exit Sensor
Control Panel
Normal
Digital Input
DI- 3 L 0
Digital Input
DI- 3 L 1
