4-56 Phaser 6128MFP Service Manual
General Troubleshooting
Troubleshooting Procedure
Applicable Parts Wiring and Plug/Jack Map References
■ Image Processor Board, PL10.6.6 ■ “Map 3 - Electrical and Drive” on
page 10-8
Troubleshooting Procedure Table
Step Actions and Questions Yes No
1 1. Check the telephone services for
screening feature such as blocking
unwanted calls, etc.
2. Is the line identified?
Go to step 2. Go to step 4.
2 1. Manually dial any local phone number
using touch tone, pulse 20PPM and
pulse 10PPM in this order.
2. Is there a connection?
Go to step 3. Request the
phone
company for
a line repair.
3 1. Manually dial any out-of-area phone
number.
2. Is there a connection?
Go to step 6. Check if the
transmission
route
consists of
multiple
telephone
service
providers.
Confirm that
your
telephone
line supports
faxing.
4 1. Check the line type.
■ Confirm that the line is not an ISDN/
xDSL/IP phone line but an analog line.
■ If no dial tone is present at Off hook,
the line may be faulty.
2. For PSTN:
■ Is there a continuous tone present at
the hook?
■ Does the cable have 2 conductors?
Manually
dial any local
phone
number
using touch
tone.
Go to step 5.
5 Is the line a PBX? Go to step 8. Request the
telephone
company for
a line repair.

Xerox Phaser 6128MFP Specifications

General

Print technology	Laser
Maximum resolution	600 x 600 DPI
Economical printing	Yes
Time to first page (black, normal)	14 s
Time to first page (color, normal)	17 s
Print speed (black, normal quality, A4/US Letter)	16 ppm
Print speed (color, normal quality, A4/US Letter)	12 ppm
Scanner type	Flatbed scanner
Image formats supported	JPG, TIF
Copier resize	- %
Time to first copy (black, normal)	18 s
Copy speed (black, normal quality, A4)	16 cpm
Copy speed (color, normal quality, A4)	12 cpm
Faxing	Mono faxing
Fax speed dialing (max numbers)	200
Total input capacity	250 sheets
Total output capacity	150 sheets
Display	LCD
Market positioning	Business
Internal memory	384 MB
Card reader integrated	No
Sound pressure level (copying)	52.2 dB
Sound pressure level (printing)	14.9 dB
Maximum print size	216 x 297 mm
Paper tray media types	Bond paper, Card stock, Envelopes, Glossy paper, Labels, Plain paper
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Legal (media size), Letter (media size), Oficio (media size), Statement (140 x 216mm)
ISO A-series sizes (A0...A9)	A4, A5
JIS B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 216 g/m²
Power supply type	AC
Dimensions (WxDxH)	425 x 507 x 585 mm
Power requirements	120 V, 50/60 Hz
Networking features	Fast Ethernet
All-in-one functions	Copy, Fax, Scan
Standard media sizes	76.2 x 127 mm - 215.6 x 355.6 mm
Color all-in-one functions	copy, print, scan
Compatible operating systems	Windows 2000+ Mac OS X v10.3 - 10.5 Red Hat Enterprise Linux 5 Desktop SUSE Linux Desktop 10+
Dimensions (W x D x H) (imperial)	16.7 x 20 x 23 \
Acoustic power emissions (active, print, copy or scan)	62.2/30.3 dB
Standard interfaces	USB 2.0
USB 2.0 ports quantity	1
Power consumption (standby)	18.4 W
Power consumption (average operating)	360 W
Sustainability certificates	ENERGY STAR
Certification	EEC, FCC
Maximum duty cycle	40000 pages per month
Recommended duty cycle	3000 pages per month
Storage temperature (T-T)	-20 - 40 °C
Operating temperature (T-T)	10 - 32 °C
Non-operating relative humidity (non-condensing)	10 - 85 %
