Phaser 6128MFP Service Manual 5-13
Print-Quality Troubleshooting
20 Reseat all IP Board connectors.
Is the image printed correctly?
Complete Go to step 21.
21 Open and close the Front Cover to
reseat the Transfer Belt.
Is the image printed correctly?
Complete Go to step 22.
22 Replace the Imaging Unit
(page 8-8).
Is the image printed correctly?
Complete Go to step 23.
23 Replace the Transfer Belt
(page 8-103)
Is the image printed correctly?
Complete Go to step 24.
24 Replace the Laser Unit. (page 8-98)
Is the image printed correctly?
Complete Replace the IP
Board
(page 8-41).
Troubleshooting Procedure Table (continued)
Step Actions and Questions Yes No
