Xerox Phaser 6128MFP Service Manual

5-12 Phaser 6128MFP Service Manual
Print-Quality Troubleshooting
12 Perform the Toner Motor test for
each color:
NOTE
Run each motor just long enough to
check operation.
Service Mode > Engine Diag >
Motor Test > Yellow/Magenta/
Cyan/Black Toner Motor (DO-
21(Y), 23(M), 25(C), 27(K))
Do the Toner Motors function
normally?
Go to step 17. Go to step 13.
13 Inspect the connectors between the
MCU Board and Toner Motor (Y/M/
C/K) (Dispenser Motor Assy).
Are P/J18, P/J19, P/J181, P/J182, P/
J191 and P/J192 connected
correctly?
Go to step 15. Securely
reconnect the
connectors,
then go to step
14.
14 Is the image printed correctly? Complete Go to step 15.
15 Check the Toner Motor Harness for
continuity:
1. Disconnect J18 and J19 from the
MCU Board.
2. Disconnect J181, J182, J191 and
J192 from the Toner Motors.
Is each cable of J18 <=> J181 and
J182 continuous?
Is each cable of J19 <=> J191 and
J192 continuous?
Go to step 16. Replace the
Dispense Assy
(page 8-91).
16 Check for power to Toner Motors (Y/
M/C/K):
1. Disconnect J18 and J19 from the
MCU Board.
2. Measure the voltage across P18-3,
P18-8, P19-4 and P19-9 <= >
ground on the MCU Board.
Is the voltage about +24 VDC when
the Front Cover interlock switch
(Interlock Harness Assy) is actuated?
Replace the
Dispense Assy
(page 8-91).
Replace the
MCU Board
(page 8-57).
17 Check the connections between the
Laser Unit and MCU Board.
Are P/J40, P/J 41, P/J411 and P/J
412 connected correctly?
Go to step 19. Reconnect the
connector(s) P/
J40, P/J41, P/
J411 and/or P/
J412 securely,
then go to step
18.
18 Is the image printed correctly? Complete Go to step 19.
19 Reseat all MCU Board connectors.
Is the image printed correctly?
Complete Go to step 20.
Troubleshooting Procedure Table (continued)
Step Actions and Questions Yes No

Xerox Phaser 6128MFP Specifications

General

Print technology	Laser
Maximum resolution	600 x 600 DPI
Economical printing	Yes
Time to first page (black, normal)	14 s
Time to first page (color, normal)	17 s
Print speed (black, normal quality, A4/US Letter)	16 ppm
Print speed (color, normal quality, A4/US Letter)	12 ppm
Scanner type	Flatbed scanner
Image formats supported	JPG, TIF
Copier resize	- %
Time to first copy (black, normal)	18 s
Copy speed (black, normal quality, A4)	16 cpm
Copy speed (color, normal quality, A4)	12 cpm
Faxing	Mono faxing
Fax speed dialing (max numbers)	200
Total input capacity	250 sheets
Total output capacity	150 sheets
Display	LCD
Market positioning	Business
Internal memory	384 MB
Card reader integrated	No
Sound pressure level (copying)	52.2 dB
Sound pressure level (printing)	14.9 dB
Maximum print size	216 x 297 mm
Paper tray media types	Bond paper, Card stock, Envelopes, Glossy paper, Labels, Plain paper
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Legal (media size), Letter (media size), Oficio (media size), Statement (140 x 216mm)
ISO A-series sizes (A0...A9)	A4, A5
JIS B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 216 g/m²
Power supply type	AC
Dimensions (WxDxH)	425 x 507 x 585 mm
Power requirements	120 V, 50/60 Hz
Networking features	Fast Ethernet
All-in-one functions	Copy, Fax, Scan
Standard media sizes	76.2 x 127 mm - 215.6 x 355.6 mm
Color all-in-one functions	copy, print, scan
Compatible operating systems	Windows 2000+ Mac OS X v10.3 - 10.5 Red Hat Enterprise Linux 5 Desktop SUSE Linux Desktop 10+
Dimensions (W x D x H) (imperial)	16.7 x 20 x 23 \
Acoustic power emissions (active, print, copy or scan)	62.2/30.3 dB
Standard interfaces	USB 2.0
USB 2.0 ports quantity	1
Power consumption (standby)	18.4 W
Power consumption (average operating)	360 W
Sustainability certificates	ENERGY STAR
Certification	EEC, FCC
Maximum duty cycle	40000 pages per month
Recommended duty cycle	3000 pages per month
Storage temperature (T-T)	-20 - 40 °C
Operating temperature (T-T)	10 - 32 °C
Non-operating relative humidity (non-condensing)	10 - 85 %
