Xerox Phaser 6128MFP Service Manual

5-36 Phaser 6128MFP Service Manual
Print-Quality Troubleshooting
6 Reseat the Fuser.
Is the image printed correctly?
Complete Go to step 7.
7 Open and close the Front Cover to
reseat the Transfer Belt.
Is the image printed correctly?
Complete Go to step 8.
8 Is the paper damaged when fed
from the manual feed slot?
Go to step 9. Go to step 12.
9 Check the setting of the manual
feed slot side guides and reset the
side guides if needed.
Is the image printed correctly?
Complete Go to step 10.
10 Inspect the media path.
Is there any contamination?
Clean the
paper path
(refer to
“Cleaning” on
page 7-2), then
go to step 11.
Go to step 12.
11 Is the image printed correctly? Complete Go to step 12.
12 Reseat the Paper Tray.
Is the image printed correctly?
Complete Go to step 13.
13 Reset the Paper Tray side guides.
Is the image printed correctly?
Complete Go to step 14.
14 Replace the media in the Paper Tray.
Is the image printed correctly?
Complete Go to step 15.
15 Inspect the media path.
Is there any contamination?
Clean the
paper path
(refer to
“Cleaning” on
page 7-2), then
go to step 16.
Go to step 17.
16 Is the image printed correctly? Complete Go to step 17.
17 Reseat the Separator Roller.
Is the image printed correctly?
Complete Go to step 18.
18 Replace the Separator Roller
(page 8-7).
Is the image printed correctly?
Complete Go to step 19.
19 Replace the Feed Roller (page 8-10).
Is the image printed correctly?
Complete Go to step 20.
Troubleshooting Procedure Table (continued)
Step Actions and Questions Yes No

Xerox Phaser 6128MFP Specifications

General

Print technology	Laser
Maximum resolution	600 x 600 DPI
Economical printing	Yes
Time to first page (black, normal)	14 s
Time to first page (color, normal)	17 s
Print speed (black, normal quality, A4/US Letter)	16 ppm
Print speed (color, normal quality, A4/US Letter)	12 ppm
Scanner type	Flatbed scanner
Image formats supported	JPG, TIF
Copier resize	- %
Time to first copy (black, normal)	18 s
Copy speed (black, normal quality, A4)	16 cpm
Copy speed (color, normal quality, A4)	12 cpm
Faxing	Mono faxing
Fax speed dialing (max numbers)	200
Total input capacity	250 sheets
Total output capacity	150 sheets
Display	LCD
Market positioning	Business
Internal memory	384 MB
Card reader integrated	No
Sound pressure level (copying)	52.2 dB
Sound pressure level (printing)	14.9 dB
Maximum print size	216 x 297 mm
Paper tray media types	Bond paper, Card stock, Envelopes, Glossy paper, Labels, Plain paper
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Legal (media size), Letter (media size), Oficio (media size), Statement (140 x 216mm)
ISO A-series sizes (A0...A9)	A4, A5
JIS B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 216 g/m²
Power supply type	AC
Dimensions (WxDxH)	425 x 507 x 585 mm
Power requirements	120 V, 50/60 Hz
Networking features	Fast Ethernet
All-in-one functions	Copy, Fax, Scan
Standard media sizes	76.2 x 127 mm - 215.6 x 355.6 mm
Color all-in-one functions	copy, print, scan
Compatible operating systems	Windows 2000+ Mac OS X v10.3 - 10.5 Red Hat Enterprise Linux 5 Desktop SUSE Linux Desktop 10+
Dimensions (W x D x H) (imperial)	16.7 x 20 x 23 \
Acoustic power emissions (active, print, copy or scan)	62.2/30.3 dB
Standard interfaces	USB 2.0
USB 2.0 ports quantity	1
Power consumption (standby)	18.4 W
Power consumption (average operating)	360 W
Sustainability certificates	ENERGY STAR
Certification	EEC, FCC
Maximum duty cycle	40000 pages per month
Recommended duty cycle	3000 pages per month
Storage temperature (T-T)	-20 - 40 °C
Operating temperature (T-T)	10 - 32 °C
Non-operating relative humidity (non-condensing)	10 - 85 %
