Phaser 6128MFP Service Manual 8-69
Service Parts Disassembly
18. Remove the 3 screws that secure the MCU chassis to the chassis.
19. Lift the MCU chassis to release the 3 hooks ro remove the MCU chassis
containing the MCU and EEPROM Boards.
Hook
Hooks
s6128mfp-244
