8-70 Phaser 6128MFP Service Manual
Service Parts Disassembly
20. Remove the 1 screw (silver, 6mm) that secures the Ground Harness to the Sub-
Drive Assembly.
21. Release all the harnesses from the Locking Clamp (PL10.5.10).
s6128mfp-245
s6128mfp-246
