Phaser 6128MFP Service Manual 8-101
Service Parts Disassembly
Note
When performing the following procedure, take care not to drop Gear T4.
10. Pull out the Left Transfer Pivot, and remove the Gear T4 from the printer.
s6128mfp-240
Gear T4
