Phaser 6128MFP Service Manual 10-3
Wiring
40 3 E-143 Connects LVPS and HARNESS ASSY IIT POWER
40 1 I-157 Connects MCU Board and HARNESS ASSY ROS RE
41 1 I-157 Connects MCU Board and HARNESS ASSY ROS
VIDEO
42 1 J-157 Connects MCU Board and HARNESS ASSY PHD
XPRO
44 3 E-143 Connects LVPS and Interlock Switch
47 3 C-143 Connects LVPS and HARNESS ASSY FUSER
48 3 C-142 Connects LVPS and HARNESS ASSY SW PWR
141 4 G-109 Connects LED ASSY ERASE and HARNESS ASSY
LVPS MAIN
144 1 G-151 Connects PWBA EEPROM and HARNESS ASSY PHD
XPRO
161 1 F-154 Connects HVPS and HARNESS ASSY HVPS
171 4 G-108 Connects FUSER and HARNESS ASSY FUSER
181 1 D-152 Connects Dispense Assy (Y toner motor) and
HARNESS ASSY TNR MOT
182 1 D-152 Connects Dispense Assy (M toner moto) and
HARNESS ASSY TNR MOT
191 1 D-151 Connects Dispense Assy (C toner moto) and
HARNESS ASSY TNR MOT
192 1 D-151 Connects Dispense Assy (K toner moto) and
HARNESS ASSY TNR MOT
201 3 H-139 Connects FEEDER ASSY NV AIO (HUM Sensor) and
HARNESS ASSY HUM
202 2 E-123 Connects CONSOLE ASSY PANEL and HARNESS
ASSY A-OP-OPP
211 3 J-137 Connects DRIVE ASSY MAIN (Main Motor) and
HARNESS ASSY MAIN MOT
221 3 I-137 Connects DRIVE ASSY SUB (Sub Motor) and
HARNESS ASSY SUB MOT
231 2 D-127 Connects FEEDER ASSY NV AIO (Feed Solenoid)
and HARNESS ASSY L SIDE
232 2 F-126 Connects FEEDER ASSY NV AIO (REGI Sensor) and
HARNESS ASSY L SIDE
233 2 G-126 Connects FEEDER ASSY NV AIO (SSI No Paper
Sensor) and HARNESS ASSY L SIDE
234 2 G-126 Connects FEEDER ASSY NV AIO (Tray No Paper
Sensor) and HARNESS ASSY L SIDE
261 3 H-138 Connects DRIVE ASSY PH (Color Mode Switching
Sensor) and HARNESS ASSY KSNR REGCL
262 3 I-138 Connects CLUTCH ASSY DRV and HARNESS ASSY
KSNR REGCL
281 4 B-110 Connects Transfer Belt (Harness Assy CTD SNR2)
and HARNESS ASSY L SIDE
Print Engine Plug/Jack Designators
P/J Map Coordiates Description
