96 Viewing Status on the Wireless AP
Access Point Status Windows
The following AP Status windows are available:
 Access Point Summary — displays information on the configuration of all
AP interfaces, including IAPs.
 Access Point Information — provides version/serial number information
for all AP components.
 Access Point Configuration — shows all configuration information for
the AP in text format.
 Admin History — shows all current and past logins since the last reboot.
Access Point Summary
This is a status only window that provides a snapshot of the global configuration
settings for all Wireless AP network interfaces and IAPs. You must go to the
appropriate configuration window to make changes to any of the settings
displayed here — configuration changes cannot be made from this window.
Clicking on an interface or IAP will take you to the proper window for making
configuration changes.
Figure 44. AP Summary
