Wireless Access Point
Configuring the Wireless AP 223
SSID Assignments
This window allows you to select the SSIDs to be bridged by each tunnel. Station
traffic for SSIDs assigned will be bridged through a tunnel regardless of whether
these SSIDs have VLANs defined for them. If there is a VLAN defined for an SSID
that is assigned to a tunnel, then station traffic bridged through that tunnel will be
tagged accordingly.
Figure 129. Tunnel SSID Assignments
Procedure for Assigning SSIDs
This window lists the tunnels and SSIDs that you have defined. SSIDs to be
tunneled do not need to be associated with a VLAN (see “SSID Management” on
page 276).
1. For each tunnel, select the SSIDs that are to be bridged to the remote
endpoint. Clear the checkbox for any SSID that you no longer wish to
include in the tunnel.
2. Click the Save button if you wish to make your changes permanent.
See Also
Tunnels
VLANs
SSIDs
