Wireless Access Point
154 Viewing Status on the Wireless AP
By Category: Check this box if you wish to analyze and list traffic by the
types of applications in use, such as Games or Collaboration.
Auto Refresh instructs the AP to periodically refresh this window
automatically. Use the Refresh button to refresh the window right now.
Pie Charts
Figure 92. Application Control (Pie Charts)
These charts provide a quick way to determine how your wireless bandwidth is
being used. There are charts for Station Traffic and/or AP Management Traffic,
depending on which checkboxes you selected. Similarly, there are charts for By
Application and/or By Category, depending on your selections. The top ten
applications or categories are listed, by percentage of bandwidth usage.
