Viewing Status on the Wireless AP 139
Statistics Windows
The following AP Statistics windows are available:
 IAP Statistics Summary — provides an overview of the statistical data
associated with all IAPs. Expands to show links for displaying detailed
statistics for individual IAPs.
 Per-IAP Statistics — provides detailed statistics for an individual IAP.
 Network Statistics — displays statistical data associated with each
network (Ethernet) interface.
 VLAN Statistics — provides statistical data associated with your assigned
VLANs.
 WDS Statistics — provides statistical data for all WDS client and host
links.
 IDS Statistics — provides statistical data for intrusion detection.
 Filter Statistics — provides statistical data for all configured filters.
 Station Statistics — provides statistical data associated with each station.
IAP Statistics Summary
This is a status only window that provides an overview of the statistical data
associated with all IAPs. It also shows the channel used by each IAP. For detailed
statistics for a specific IAP, see “Per-IAP Statistics” on page 140. Click the Unicast
Stats Only checkbox on the lower left to filter the results, or clear the checkbox to
show statistics for all wireless traffic.
Figure 81. IAP Statistics Summary Page
You can Refresh the data (update the window with the latest information) or
Clear the data (reset all content to zero and begin counting again) at any time by
