Viewing Status on the Wireless AP 127
Stations
This window shows client stations currently visible to the AP. You may choose to
view only stations that have Associated to the AP, or include stations that are
Unassociated by selecting the appropriate buttons above the list. The list always
shows the MAC address of each station, its IP address, the SSID used for the
association, the Group (if any) that this station belongs to, its VLAN, its QoS, the
IAP used for the association, transmit and receive rates, the RSSI for each station,
and how long each association has been active (up time).
In the Link column, click the details button to jump to a detailed statistics
page for this station. Click to see Application Control information.
You may click other buttons above the list to show a number of additional
columns:
 Identification: shows more identifying information for the station — its
User Name, Host Name, Manufacturer, Device Type, and Device Class
(for example, notebook, iPad, etc.).
 Security: includes security settings used by the connection — Encryption
type, Cipher used, and Key Management used by the station.
 Connection Info: shows the Band (5GHz or 2.4 GHz) used. Shows an
additional RF measurement that affects the quality of the connection:
SNR (signal to noise ratio).
 Reset: click this button to return the display to showing just the default
columns.
Figure 70. Stations
