Xirrus XR Series User Manual

Wireless Access Point
14 Introduction
XR-6000 Series 8- to 16-Radio High Density Access Points
These APs include models with four Gigabit Ethernet ports and up to sixteen
radios, connecting up to 3840 users at one time and offering a maximum wireless
bandwidth of 7.2 Gbps (up to 450 Mbps per radio). Smaller models may be
upgraded to sixteen radios later when your needs change. A 10 Gigabit modular
Ethernet expansion port (DVI connector) is available to meet high traffic
demands. It is used only with an optional Xirrus 10 Gig fiber optics adapter.
Enterprise Class Security
The latest and most effective wireless encryption security standards, including
Wireless Protected Access (WPA) and WPA2 with 802.11i Advanced Encryption
Standard (AES) are available on the Wireless AP. In addition, the use of an
embedded RADIUS server (or 802.1x with an external RADIUS server) ensures
user authentication — multiple APs can authenticate to the XMS, ensuring only
authorized APs become part of the wireless network. With the Xirrus Advanced
Feature XR-6820 XR-6830 XR-7620 XR-7630
Number of radios:
802.11a/b/g/n/monitor
881616
Radio type 2x2 3x3 2x2 3x3
Number of 
integrated antennas
16 24 32 48
Integrated wireless switch
ports
16 16 16 16
Integrated RF spectrum
analyzer, threat sensors
Yes Yes Yes Yes
1 Gigabit Uplink Ports 4 4 4 4
External 10 Gigabit Modular
Expansion Port
1111
Wireless bandwidth (Gbps) 2.4 3.6 4.8 7.2
Users supported 1920 1920 3840 3840
