Wireless Access Point
Introduction 11
XR-2005 Series 2- and 4-Radio Access Points
These APs include models with one or two Gigabit Ethernet ports and two or four
multi-state radios (2.4GHz or 5GHz) that can support 300Mbps or 450Mbps,
connecting up to 960 users at one time.
The Xirrus XR-2005 Series Wireless AP has a four slot chassis available in a multi-
state (2.4GHz or 5GHz) radio configuration supporting up to 1.8Gbps of
bandwidth. These models support a range of low to high-performance
applications, including offices, hospitals, campuses and classrooms, and hotels.
Like larger XR APs, these models integrate multi-state radios with high gain
directional antennas, an onboard multi-gigabit switch, controller, firewall, threat
sensor and spectrum analyzer on a modular chassis designed for extensibility.
XR-2005 Series APs have no console port, but have two Gigabit ports, one of
which accepts POE+ power supplied by a Xirrus-supplied power injector or an
IEEE802.3at powered switch. Note that older XR-2000 Series APs ending in “0”
have one Gigabit POE port and a Console port.
Feature
XR-2225 XR-2235 XR-2425 XR-2435
No. radios: 802.11
a/b/g/n/monitor
2244
Radio type 2x2 3x3 2x2 3x3
Integrated antennas 4 6 8 12
Integrated wireless
switch ports
4444
Integrated RF spectrum
analyzer, threat sensors
Yes Yes Yes Yes
Gigabit Uplink Ports 2222
Wireless bandwidth 600 Mbps 900 Mbps 1.2 Gbps 1.8 Gbps
Users supported 480 480 960 960
