Wireless Access Point
Installing the Wireless AP 73
AP LED Operating Sequences
Use the following tables to review the operating sequences of the AP’s LEDs.
“LED Boot Sequence” on page 73
“LED Operation when AP is Running” on page 74
LED Boot Sequence
The normal boot LED sequence is as follows:
AP Activity Status LED IAP LEDs
Power ON Blinking GREEN All OFF
Boot loader power ON
self-test
Blinking GREEN All ON
Image load from
compact FLASH
Blinking GREEN Spinning pattern (rotate all
to ON, then all to OFF)
Image load failure Blinking ORANGE All OFF
Hand off to ArrayOS Solid GREEN All OFF
System software
initialization
Solid GREEN Walking pattern — (LED
rotating one position per
second)
Up and running Solid GREEN ON for IAPs that are up:
OFF for IAPs that are down.
Green or orange per table on
the next page.
Behavior may be changed
using “LED Settings” on
page 378.
