Configuring the Wireless AP 387
StoredRSSI = (StoredRSSI * RoamingAvgWeight
+ NewRSSIReading * (100 - RoamingAvgWeight)) / 100
This prevents erroneous or out-of-line RSSI readings from causing the
WDS link to jump to a new AP. Such readings can result from temporary
obstructions, external interference, etc.
4. Click the Save button after you are finished making changes on this
page if you wish to make your changes permanent.
WDS Client Link Setting:
5. Enable/Disable/Reset All Links: Click the appropriate button to:
• Enable All Links—this command activates all WDS links configured
on the AP.
• Disable All Links—this command deactivates all WDS links
configured on the AP. It leaves all your settings unchanged, ready to
re-enable.
• Reset All Links—this command tears down all links configured on
the AP and sets them back to their factory defaults, effective
immediately.
6. Client Link: Shows the ID (1 to 4) of each of the four possible WDS links.
7. Enabled: Check this box if you want to enable this WDS link, or uncheck
the box to disable the link.
8. Max IAPs Allowed (1-3): Enter the maximum number of IAPs for this
link, between 1 and 3.
9. Target AP Base MAC Address: Enter the base MAC address of the target
AP (the host AP at the other side of this link). To find this MAC address,
open the WDS window on the target AP, and use This AP Address
located on the right under the Summary of WDS Host Links. To allow any
Xirrus AP to be accepted as a WDS target, enter the Xirrus OUI:
00:0f:7d:00:00:00 or 50:60:28:00:00:00 (this is useful for roaming in a
mobile deployment, as described in Step 2 on page 386).
10. Target SSID: Enter the SSID that the target AP is using.
