ABB AC500 V3 - Page 379

When a wire break occurs on a sensor wire, the temperature measurement
value of the corresponding channel changes to Overflow (Hexadecimal 7FFF).
Range Type J
-210 ...
+1200 °C
Type K
-270 ...
+1372 °C
Type N
-270 ...
+1300 °C
Type T
-270 ...
+400 °C
Digital value
Decimal Hex.
Overflow > 1200.0 °C > 1372.0 °C > 1300.0 °C > 400.0 °C 32767 7FFF
Normal
range
17680 4510
1372.0 °C 13720 3598
: 1300.0 °C 13000 32C8
1200.0 °C : : 12000 2EE0
: : : 400.0 °C 4000 0FA0
: : : : : :
0.1 °C 0.1 °C 0.1 °C 0.1 °C 1 1
0.0 °C 0.0 °C 0.0 °C 0 0000
-0.1 °C -0.1 °C -0.1 °C -0.1 °C -1 FFFF
: : : : : :
: : : : -500 FE0C
-210.0 °C : : : -2100 F7CC
-270.0 °C -270.0 °C -270.0 °C -2700 F574
Underflow < -210.0 °C < -270.0 °C < -270.0 °C < -270.0 °C -32768 8000
Range -80 mV ... +80
mV
Type E
-270 ... +1000
°C
Types R, S
-50 ... +1768
°C
Digital value
Decimal Hex.
Overflow > +90 mV > 1000.0 °C > 1768.0 °C 32767 7FFF
Normal range +80 mV 27648 6C00
1768.0 °C 17680 4510
1000.0 °C 10000 2710
9000 2328
: : : : :
3 µV 0.1 °C 0.1 °C 1 1
0 µV 0.0 °C 0.0 °C 0 0000
-3 µV -0.1 °C -0.1 °C -1 FFFF
: : : : :
: : -50.0 °C -500 FE0C
: -270.0 °C -2700 F574
Device specifications
I/O modules > Analog I/O modules
2022/01/31 3ADR010278, 3, en_US 379
