3CALCulate Subsystem
166 N1911A/1912A P-Series Power Meters Programming Guide
Parameters
Example
Reset Condition
On reset, data_handle is set to :POW:AVER.
Item Description Range of Values
string The input measurement type to be fed to the specific input
on the CALC block:
• PEAK: peak power
• PTAV: peak to average
• AVER: average
• MIN: minimum power
Values may be followed by ON SWEEP[1]|2|3|4
where the numeric specifies the gate to be used for the
feed. For example: “POW:PEAK ON SWEEP2”.
If ON SWEEP[1]|2|3|4 is not supplied, the gate used is
left unchanged.
A feed of “” (empty string) disables the CALC block and
switches off that display line.
“POW:PEAK”
“POW:PTAV”
“POW:AVER”
“POW:MIN”
CALC3:FEED2 “POW:AVER ON
SWEEP2”
This command selects the input for FEED2
of CALC block CALC3 to be average power,
using gate 2. The channel from which the
feed is taken is determined by
CALC:MATH:EXPR..
