PSTatistic Subsystem 9
N1911A/1912A P-Series Power Meters Programming Guide 321
PSTatistic:CCDF:REFerence:DATa?
This command is used to retrieve the reference trace data and it is
independent of the channel attached. The reference trace data will be
returned only if there is a reference trace saved.
Syntax
Example
Reset Condition
On reset, the trace will be cleared.
This command is only applicable when P-Series sensors are present and the following
conditions are met:
• Free-run acquisition mode is selected
• NORMal or DOUBle measurement speed setting is chosen
The reference trace data returned in the format as shown below:
• The reference trace data maximum X-axis value in dB
• 501 points of the reference trace data
PST:CCDF:REF:DAT? This command returns the previously
saved reference trace data.
