12 SYSTem Subsystem
552 N1911A/1912A P-Series Power Meters Programming Guide
BLUetooth
The Bluetooth set- up provides:
• Average power in a Bluetooth DH1 data burst.
• Peak power in the same burst
• Display of RF pulse in one timeslot
The measurement is started by detecting the Bluetooth RF burst using the
internal RF level trigger. The internal trigger is set to –20 dBm.
Time- gating is used to measure the peak and average power in a single
Bluetooth DHI data burst which lasts for 366 us. The DHI burst does not
occupy a full Bluetooth timeslot, which lasts for 625 µs.
The following table shows the power meter presets when <character_data>
is set to BLUetooth. Commands not listed are preset according to their
DEFault values (for further information refer to Table 12- 26):
Tab le 12-42 BLUetooth: Power Meter Presets
Command Setting Comments
Frequency
[SENS[1]]|SENS2:FREQ[:CW|:FIX] +2400.000 MHz Frequency setting
Sensor measurement mode
[SENS[1]]|SENS2:DET:FUNC NORM Measurement mode
Sensor video bandwidth setup
[SENS[1]]|SENS2:BAND|BWID:VID E9321A/25A: DEF
E9322A/26A: OFF
E9323A/27A: OFF
N1921/2A: OFF
Sensor video bandwidth
Gate Setup
[SENS[1]]|SENS2:SWE[1]|2|3|4
:OFF:TIME
Gate 1: 0.2 µs
Gates 2 - 4: 0
Delay between trigger point and time
gated period.
[SENS[1]]|SENS2:SWE[1]|2|3|4
:TIME
Gate 1: 366 µs
Gates 2 - 4: 0
Length of time gated period for time
gated measurements.
Trigger setup
TRIG[:SEQ[1]|2]:SOUR INT1 Trigger source set up and acquisition
mode continuous triggering
INIT:CONT ON
