12 SYSTem Subsystem
590 N1911A/1912A P-Series Power Meters Programming Guide
Tab le 12-77 WiMAX: Power Meter Presets For Secondary Channel Sensors
Measurement Avg See Table 12-77
Lower window/lower measurement (LL)
Feed Gate 2 Channel A See Table 12-77
Measurement Pk-to-Avg See Table 12-77
* For further information refer to “Primary and Secondary Channels” on page 526.
Function Setting
Single Channel Dual Channel
Function Secondary Channel Sensor
No Sensor Non P-Series or E9320
Sensor
P-Series and E9320
Sensor
Display setup
Upper window Dual numeric Dual numeric Dual numeric
Lower window Dual numeric Dual numeric Dual numeric
Upper window/lower measurement (UL)
Feed
Gate 1 primary channel
*
Gate 1 primary channel
*
Gate 1 primary channel
*
Measurement Pk-to-Avg Pk-to-Avg Pk-to-Avg
Lower window/upper measurement (LU)
Feed
Gate 2 primary channel
*
Gate 2 primary channel
*
Gate 1 secondary channel
*
(Channel B)
Measurement Avg Avg Avg
Lower window/lower measurement (LL)
Feed
Gate 2 primary channel
*
Secondary channel
*
Gate 1 secondary channel
*
(Channel B)
Measurement Pk-to-Avg Avg Pk-to-Avg
* For further information refer to “Primary and Secondary Channels” on page 526.
