13 TRACe Subsystem
634 N1911A/1912A P-Series Power Meters Programming Guide
TRACe[1]|2:MEASurement:TRANsition[1]|...|10:POSitive:OCCu
rrence?
This command returns the position, relative to the trigger instant, of the
n
th
occurrence of a positive transition found on a trace.
Syntax
Reset Condition
On reset, this parameter is not affected.
Example
Error Messages
• If a P- Series sensor is not connected, error –241, “Hardware missing”
occurs.
• If a P- Series sensor is connected and Free Run trigger acquisition is
selected, error –221, “Settings conflict” occurs.
TRAC
:MEAS
1
2
:TRAN
:POS
:OCC
?
1
2|...|10
TRAC2:MEAS:TRAN:POS:OCC? This command returns the position,
relative to the trigger instant, of the 1st
occurrence of a positive transition
found on trace 2.
