SYSTem Subsystem 12
N1911A/1912A P-Series Power Meters Programming Guide 603
1
The Range setting in Ta b l e 1 2 - 8 7 is only applicable for E-Series power sensor and N8480 Series
power sensor (excluding Option CFT).
Tab le 12-88 LTE: Power Meter Presets: Window/Measurement Settings
[SENS[1]]|SENS2:POW:AC:RANG:AUTO OFF Auto range off
[SENS[1]]|SENS2:POW:AC:RANG UPPER Range set to upper
Step detection
[SENSe[1]]|SENS2:AVER:SDET 0 Step detection is disabled
Trace setup
[SENS[1]]|SENS2:TRAC:OFFS
:TIME <numeric_value>
–0.2 ms Delay between delayed trigger point
and the start of the trace
[SENS[1]]|SENS2:TRAC:TIME
<numeric_value>
11.0
ms
Length of the trace
Command Setting Comments
Function Setting
Single Channel Dual Channel
Display setup
Upper window Channel A trace
Primary channel
*
trace
Lower window Dual numeric See Table 12-89
Window/measurement setup
Upper window/upper measurement (UU)
Feed N/A N/A
Measurement N/A N/A
Upper window/lower measurement (UL)
Feed N/A N/A
Measurement N/A N/A
Lower window/upper measurement (LU)
Feed Gate 1 Channel A See Table 12-89
Measurement Avg See Table 12-89
Lower window/lower measurement (LL)
