12 SYSTem Subsystem
542 N1911A/1912A P-Series Power Meters Programming Guide
Tab le 12-35 CDMAone: Power Meter Presets For Secondary Channel Sensors
Window/measurement setup
Upper window/upper measurement (UU)
Feed Gate 1 Channel A
Gate 1 primary channel
*
Measurement Avg Avg
Upper window/lower measurement (UL)
Feed DEF See Table 12-35
Measurement DEF See Table 12-35
Lower window/upper measurement (LU)
Feed Gate 1 Channel A See Table 12-35
Measurement Peak See Table 12-35
Lower window/lower measurement (LL)
Feed Gate 1 Channel A See Table 12-35
Measurement Pk-to-Avg See Table 12-35
* For further information refer to “Primary and Secondary Channels” on page 526.
Function Setting
Single Channel Dual Channel
Function Secondary Channel Sensor
No Sensor Non P-Series or E9320
Sensor
P-Series and E9320
Sensor
Display setup
Upper window UU single numeric Dual numeric Dual numeric
Lower window Dual numeric Dual numeric Dual numeric
Upper window/lower measurement (UL)
Feed DEF
Gate 1 primary channel
*
Gate 1 primary channel
*
(Channel A)
Measurement DEF Peak Peak
Lower window/upper measurement (LU)
