10 SENSe Subsystem
378 N1911A/1912A P-Series Power Meters Programming Guide
[SENSe[1]]|SENSe2:BANDwidth|BWIDth:VIDeo
<character_data>
This command sets the sensor bandwidth on a P- Series or an E9320
Series sensor.
Syntax
Parameters
Values for HIGH, MEDIUM, LOW and OFF are sensor dependant as shown
in the following table:
Item Description/Default Range of Values
character_data Defines the sensor bandwidth. HIGH
MEDium
LOW
OFF
SENS
1
:VID
BAND
SENS2
:
BWID
Space
?
character_data
Video Bandwidth Settings
Sensor LOW MEDium HIGH OFF
E9321A
E9325A
30 kHz 100 kHz 300 kHz
300 kHz
1
E9322A
E9326A
100 kHZ 300 kHz 1.5 MHz
1.5 MHz
1
E9323A
E9327A
300 kHz 1.5 MHz 5 MHz
5 MHz
1
