STATus Subsystem 11
N1911A/1912A P-Series Power Meters Programming Guide 477
STATus:OPERation:CALibrating[:SUMMary]
The operation status calibrating summary register set contains information
on the calibrating status of the power meter.
The following bits in these registers are used by the power meter:
These bits are set at the beginning of zeroing (CALibration:ZERO:AUTO
ONCE) and at the beginning of calibration (CALibration:AUTO ONCE). Also
for the compound command/query CALibration[:ALL]?, this bit is set at
the beginning of the calibration sequence.
These bits are cleared at the end of zeroing or calibration.
Syntax
Bit Number Decimal
Weight
Definition
0- Not used
1 2 Channel A CALibrating Status
2 4 Channel B CALibrating Status (N1912A only)
3-15 - Not used
