12 SYSTem Subsystem
586 N1911A/1912A P-Series Power Meters Programming Guide
1
The Range setting in Ta b l e 1 2 - 7 2 is only applicable for E-Series power sensor and N8480 Series
power sensor (excluding Option CFT).
Tab le 12-73 DVB: Power Meter Presets: Window/Measurement Settings
TRIG[:SEQ]:HOLD 20 ms Trigger holdoff
Range
1
[SENS[1]]|SENS2:POW:AC:RANG:AUTO OFF Auto range off
[SENS[1]]|SENS2:POW:AC:RANG UPPER Range set to upper
Step detection
[SENSe[1]]|SENS2:AVER:SDET 1 Step detection enabled
Command Setting Comments
Function Setting
Single Channel Dual Channel
Display setup
Upper window UU single numeric See Table 12-74
Lower window Dual numeric See Table 12-74
Window/measurement setup
Upper window/upper measurement (UU)
Feed Gate 1 Channel A
Gate 1 primary channel
*
Measurement Avg Avg
Upper window/lower measurement (UL)
Feed DEF See Table 12-74
Measurement DEF See Table 12-74
Lower window/upper measurement (LU)
Feed Gate 1 Channel A See Table 12-74
Measurement Pk-to-Avg See Table 12-74
Lower window/lower measurement (LL)
Feed Gate 2 Channel A See Table 12-74
Measurement Avg See Table 12-74
