DISPlay Subsystem 5
N1911A/1912A P-Series Power Meters Programming Guide 235
DISPlay[:WINDow[1]|2]:METer:LOWer <numeric_value>
This command sets the analog meter lower scale limit.
The units used are dependent on the current setting of UNIT:POWer and
CALCulate:RELative:STATe as shown in Table 5- 17.
Tab le 5-1 7 Measurement Units
This command has the same purpose as DISPlay[:WINDow[1]|2]:ANALog:LOWer
<numeric_value>.
Measurement Mode Measurement Type CALC:REL:STAT OFF CALC:REL:STAT ON
Linear Log Linear Log
Single Channel Avg, Pk Watt dBm % dB
Pk–Avg % dB % dB
Ratio Avg, Pk, Pk–Avg % dB % dB
Difference Avg, Pk Watt dBm % dB
Pk–Avg % dB % dB
