SYSTem Subsystem 12
N1911A/1912A P-Series Power Meters Programming Guide 579
1
The Range setting in Ta b l e 1 2 - 6 6 is only applicable for E-Series power sensor and N8480 Series
power sensor (excluding Option CFT).
Tab le 12-67 NADC: Power Meter Presets: Window/Measurement Settings
Tab le 12-68 NADC: Power Meter Presets For Secondary Channel Sensors
Function Setting
Single Channel Dual Channel
Display setup
Upper window Channel A trace
Primary channel
*
trace
Lower window Dual numeric See Table 12-68
Window/measurement setup
Upper window/upper measurement (UU)
Feed N/A N/A
Measurement N/A N/A
Upper window/lower measurement (UL)
Feed N/A N/A
Measurement N/A N/A
Lower window/upper measurement (LU)
Feed Gate 1 Channel A
Gate 1 primary channel
*
Measurement Avg Avg
Lower window/lower measurement (LL)
Feed Gate 2 Channel A See Table 12-68
Measurement Avg See Table 12-68
* For further information refer to “Primary and Secondary Channels” on page 526.
Function Secondary Channel Sensor
No Sensor Non P-Series or E9320
Sensor
P-Series and E9320
Sensor
Display setup
