SYSTem Subsystem 12
N1911A/1912A P-Series Power Meters Programming Guide 545
1
The Range setting in Table 12-36 is only applicable for E-Series power sensor and N8480
Series power sensor (excluding Option CFT).
Tab le 12-37 cdma2000: Power Meter Presets: Window/Measurement Settings
[SENS[1]]|SENS2:SWE[1]|2|3|4
:TIME
Gate 1: 10 ms
Gates 2 - 4: 0
Length of time gated period for time
gated measurements.
Trigger setup
TRIG[:SEQ[1]|2]:SOUR INT1 Trigger source set up and acquisition
mode continuous triggering
INIT:CONT ON
TRIG[:SEQ]:LEV:AUTO ON Enable automatic setting of the trigger
level
TRIG[:SEQ]:LEV AUTO Automatic Power level
TRIG[:SEQ]:SLOP POS Trigger event recognized on the rising
edge of a signal
TRIG[:SEQ]:DEL 0 s Delay between recognition of trigger
event and start of a measurement
TRIG[:SEQ]:HOLD MIN Trigger holdoff
Range
1
[SENS[1]]|SENS2:POW:AC:RANG:AUTO OFF Auto range off
[SENS[1]]|SENS2:POW:AC:RANG UPPER Range set to upper
Step detection
[SENSe[1]]|SENS2:AVER:SDET 0 Step detection disabled
Command Setting Comments
Function Setting
Single Channel Dual Channel
Display setup
Upper window UU single numeric UU single numeric
Lower window Dual numeric See Table 12-38
Window/measurement setup
