SYSTem Subsystem 12
N1911A/1912A P-Series Power Meters Programming Guide 581
iDEN
The iDEN set- up provides:
• Average power in one iDEN training and data pulse
• Peak- to- average one iDEN training and data pulse
• Average power in a 90ms iDEN frame
The measurement is started by detecting the iDEN training burst—for
example the burst emitted by a mobile—using the internal RF level trigger.
Time gating is used to measure the average power in the following 15 ms
(data pulse). Gate 1 is used to measure this data pulse. The 90 ms frame
is also captured to measure the average power in the entire frame. Gate 2
is used to measure the 90 ms frame.
The following table shows the power meter presets when <character_data>
is set to IDEN. Commands not listed are preset according to their DEFault
values (for further information refer to Table 12- 26):
Tab le 12-69 iDEN: Power Meter Presets
Command Setting Comments
Frequency
[SENS[1]]|SENS2:FREQ[:CW|:FIX] +800.000 MHz Frequency setting
Sensor measurement mode
[SENS[1]]|SENS2:DET:FUNC NORM Measurement mode
Sensor video bandwidth setup
[SENS[1]]|SENS2:BAND|BWID:VID E9321A/25A: OFF
E9322A/26A: OFF
E9323A/27A: OFF
N1921/2A: OFF
Sensor video bandwidth
Gate Setup
[SENS[1]]|SENS2:SWE[1]|2|3|4
:OFF:TIME
Gate 1: 0
µs
Gates 2 - 4: 0
Delay between trigger point and time
gated period.
