12 SYSTem Subsystem
556 N1911A/1912A P-Series Power Meters Programming Guide
1
The Range setting in Ta b l e 1 2 - 4 5 is only applicable for E-Series power sensor and N8480 Series
power sensor (excluding Option CFT).
Tab le 12-46 MPCA: Power Meter Presets: Window/Measurement Settings
[SENS[1]]|SENS2:POW:AC:RANG UPPER Range set to upper
Step detection
[SENSe[1]]|SENS2:AVER:SDET 0 Step detection disabled
Command Setting Comments
Function Setting
Single Channel Dual Channel
Display setup
Upper window UU single numeric UU single numeric
Lower window Dual numeric See Table 12-47
Window/measurement setup
Upper window/upper measurement (UU)
Feed Gate 1 Channel A
Gate 1 primary channel
*
Measurement Avg Avg
Upper window/lower measurement (UL)
Feed DEF See Table 12-47
Measurement DEF See Table 12-47
Lower window/upper measurement (LU)
Feed Gate 1 Channel A See Table 12-47
Measurement Peak See Table 12-47
Lower window/lower measurement (LL)
Feed Gate 1 Channel A See Table 12-47
Measurement Pk-to-Avg See Table 12-47
* For further information refer to “Primary and Secondary Channels” on page 526.
