N1911A/1912A P-Series Power Meters Programming Guide 593
Tab le 12-80 DME: Power Meter Presets For Secondary Channel Sensors
Window/measurement setup
Upper window/upper measurement (UU)
Feed Gate 1 Channel A See Table 12-80
Measurement Avg See Table 12-80
Upper window/lower measurement (UL)
Feed Gate 2 Channel A See Table 12-80
Measurement Avg See Table 12-80
Lower window/upper measurement (LU)
Feed Gate 1 Channel A See Table 12-80
Measurement Peak See Table 12-80
Lower window/lower measurement (LL)
Feed Gate 2 Channel A See Table 12-80
Measurement Peak See Table 12-80
Function Setting
Single Channel Dual Channel
Function Secondary Channel Sensor
No Sensor Non P-Series or E9320
Sensor
P-Series and E9320
Sensor
Display setup
Upper window
Primary channel trace
*
Dual numeric Dual numeric
Lower window Dual numeric Single numeric Dual numeric
Upper window/upper measurement (UU)
Feed
Gate 1 primary channel
*
Gate 1 primary channel
*
Gate 1 primary channel
*
Measurement Avg Peak Peak
Upper window/lower measurement (UL)
Feed
Gate 2 primary channel
*
Gate 2 primary channel
*
Gate 2 primary channel
*
Measurement Avg Peak Peak
Lower window/upper measurement (LU)
