7MEMory Subsystem
262 N1911A/1912A P-Series Power Meters Programming Guide
MEMory:CATalog:TABLe?
This command is used to list the stored sensor calibration (8480 Series
sensors and N8480 Series sensors with Option CFT only) and frequency
dependent offset tables.
The power meter returns the data in the form of two numeric parameters
and as many strings as there are stored tables.
<numeric_value>,<numeric_value>{,<string>}
• The first numeric parameter indicates the amount of memory, in bytes,
used for the storage of tables.
• The second parameter indicates the memory, in bytes, available for the
storage of tables.
• Each string parameter returned indicates the name, type and size of a
stored table:
• <string>,<type>,<size>
• <string> indicates the name of the table.
• <type> indicates TABL for a table.
• <size> indicates the size of the table in bytes.
For example, a sample of a response may look like:
1178,10040,"DEFAULT,TABL,14","8481A,TABL,116",
"8482A,TABL,74","8483A,TABL,62"...........
The power meter is shipped with a set of predefined sensor calibration
tables. The data in these sensor calibration tables is based on statistical
averages for a range of Agilent Technologies power sensors. These tables
can be edited. The predefined data is listed in your user’s guide. These
power sensors and table numbers are listed in Table 7- 20.
Predefined sensor calibration table is not applicable for N8480 Series power sensors with
Option CFT. Therefore you are required to create a new sensor calibration table for the
sensors when a sensor calibration table is needed.
