12 SYSTem Subsystem
604 N1911A/1912A P-Series Power Meters Programming Guide
Tab le 12-89 LTE: Power Meter Presets For Secondary Channel Sensors
Feed Gate 1 Channel A See Table 12-89
Measurement Pk-to-Avg See Table 12-89
Function Setting
Single Channel Dual Channel
Function Secondary Channel Sensor
No Sensor Non P-Series or E9320
Sensor
P-Series and E9320
Sensor
Display setup
Lower window Dual numeric Dual numeric Dual numeric
Lower window/upper measurement (LU)
Feed
Gate 1 primary channel
*
Gate 1 primary channel
*
Gate 1 primary channel
*
Measurement Avg Avg Avg
Lower window/lower measurement (LL)
Feed
Gate 1 primary channel
*
Gate 1 primary channel
*
Gate 1 primary channel
*
Measurement Pk-to-Avg Pk-to-Avg Pk-to-Avg
* For further information refer to “Primary and Secondary Channels” on page 526.
