3CALCulate Subsystem
162 N1911A/1912A P-Series Power Meters Programming Guide
CALCulate Subsystem
The CALCulate subsystem performs post acquisition data processing.
Functions in the SENSe subsystem are related to data acquisition, while
the CALCulate subsystem operates on the data acquired by a SENSe
function.
There are four independent CALCulate blocks in the power meter: two for
each window, as shown in Figure 3- 18. The numeric suffix of the
CALCulate command determines which CALCulate block is used and
where the measurement result is displayed.
Figure 3-18 Measurement Display CALCulate Block Window
Data from both SENSe blocks may feed any or all of the CALCulate blocks
via the MATH command. Figure 3- 18 details where the commands are
applied with in the CALCulate block.
upper window/upper measurement
CALC1
upper window/lower measurement
CALC3
lower window/upper measurement
CALC2
lower window/lower measurement
CALC4
