4.4 OVERLAP WINDOW FUNCTION
GP monitors user-defined of 2 screen overlap devices and overlaps the screen satisfying current value
of the device on a base screen.
In order to use screen overlap function, configure device for overlap window in GP Editor.
The overlap window is displayed in order of window 1, 2 on current screens as below.
In case, the value of overlap window device is exceeded the range (1~500) or not existed, the window
is not displayed.
Base screen number
2
Base screen number
4
Base screen number
3
Base screen number
1
Base screen number
6
Base screen number
5
Base screen number
7
Screen data device : D0[1]
Overlap device 1 : D1[3]
Overlap device 2 : D2[5]
Base screen number
2 6 7
Base screen number
1 3 5
Screen data device : D0[2]
Overlap device 1 : D1[6]
Overlap device 2 : D2[7]
