70
Select object-Tag
Group
Ungroup
Bring to forward
Ctrl+F
Move selected object to the forward
Send to backward
Ctrl+B
Move selected object to the backward
Replace device
Change device used for tag and it is available to select
applicable range as all project, current screen, selected
object, used device for common configuration.
screen
Change overlapped screen as other screen
Attribution
Edit attribution of selected object
Alignment
Align screen arrangement of selected object
Draw
Panel Kit
Panel Kit, panel kit registration, Drawing on screen, Save as
Part
Register selected object as part, Draw registered part on
screen, Part library operation etc.
Line
Able to draw lines, create a straight line connecting 2 points
and configure color and style of line.
Rectangle
Able to draw rectangles, configure color, style of outline and
pattern filled inside of rectangle.
Circle
Able to draw circles, color, pattern filled inside of outline and
make an oval pulling a line.
Text
Able to draw text, configure color and size.
Bitmap
Numeric input
Create numeric input tags and configure value of designated
word device with key window.
ASCII input
Create ASCII input tags and configure value of designated
word device as ASCII code with key window.
Numeric display
Create numeric display tag, display numeric value saved in
ASCII display
Create ASCII display tag, display ASCII value saved in PLC
Clock display
Create clock display tag, display current time or date
Comment display
Create comment display tag, display designated comment in
accordance with change of designated PLC device value or
Alarm history
Create alarm history tag, write alarm history.
Alarm list
Create alarm list tag, display alarm list.
Part display
Create part display tag, display designated part in accordance
with change of designated PLC device value or status.
Lamp
Create lamp tag, display designated type of lamp in
