D-Link DWL-2600AP User Manual

Viewing System Statistics
D-Link Unified Wired and Wireless Access System
Oct. 2015 Page 166
D-Link UWS User Manual
Unicast Packets Transmitted The total number of packets that higher-level protocols requested be
transmitted to a subnetwork-unicast address, including those that were
discarded or not sent.
Multicast Packets
Transmitted
The total number of packets that higher-level protocols requested be
transmitted to a Multicast address, including those that were discarded or not
sent.
Broadcast Packets
Transmitted
The total number of packets that higher-level protocols requested be
transmitted to the Broadcast address, including those that were discarded or
not sent.
Transmit Errors
Total Transmit Errors The sum of Single, Multiple, and Excessive Collisions.
Tx FCS Errors The total number of packets transmitted that had a length (excluding framing
bits, but including FCS octets) of between 64 and 1518 octets, inclusive, but
had a bad Frame Check Sequence (FCS) with an integral number of octets
Tx Oversized The total number of frames that exceeded the max permitted frame size. This
counter has a max increment rate of 815 counts per second at 10 Mb/s.
Underrun Errors The total number of frames discarded because the transmit FIFO buffer
became empty during frame transmission.
Transmit Discards
Total Transmit Packets
Discarded
The sum of single collision frames discarded, multiple collision frames
discarded, and excessive frames discarded.
Total Output Packets Drops The total number of Aged packets.
Single Collision Frames A count of the number of successfully transmitted frames on a particular
interface for which transmission is inhibited by exactly one collision.
Multiple Collision Frames A count of the number of successfully transmitted frames on a particular
interface for which transmission is inhibited by more than one collision.
Excessive Collision Frames A count of frames for which transmission on a particular interface fails due to
excessive collisions.
Late Collision Frames Total number of collisions that occur after 512 bit collision window has
passed.
Port Membership Discards The number of frames discarded on egress for this port due to egress filtering
being enabled.
Lost/No Carrier Frames Loss of the carrier detection occurs when the carrier signal of the hardware is
undetectable. It could be because the carrier signal was not present or was
present but could not be detected. Each such event causes this counter to
increase.
Protocol Statistics
BPDUs Received Number of BPDUs received at the selected port.
BPDUs Transmitted Number of BPDUs transmitted from the selected port.
R BPDUs Received Number of R BPDUs received at the selected port.
R BPDUs Transmitted Number of R BPDUs transmitted from the selected port.
M BPDUs Received Number of M BPDUs received at the selected port.
M BPDUs Transmitted Number of M BPDUs transmitted from the selected port.
Table 72: Detailed Port Statistics Fields (Cont.)
Field Description

D-Link DWL-2600AP Specifications

General

Networking standards	IEEE 802.3af
Ethernet LAN data rates	10, 100 Mbit/s
Maximum data transfer rate	300 Mbit/s
Internal	Yes
LED indicators	Power, Stand-by, Status, WAN, WLAN
WAN connection	Ethernet (RJ-45)
Ethernet LAN (RJ-45) ports	1
Security algorithms	WEP, WPA, WPA2
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Width	160 mm
Height	45 mm
Weight	240 g
Dimensions (WxDxH)	160 x 160 x 45 mm
