Digi IX20 User Manual

Interfaces WideArea Networks(WANs)
IX20 User Guide
142
a. Click Network >Interfaces.
b. For Add Interface, type WWAN_Publicand click .
c. For Interface type, select Modem.
d. For Zone, select External.
e. For Device, select Modem .
f. (Optional): Configure the public APN. If the public APNis not configured, the IX20 will
attempt to determine the APN.
i. Click to expand APN list >APN.
ii. For APN, typethe public APN for your cellular carrier.
g. For Add Interface, typeWWAN_Private and click .
h. For Interface type, select Modem.
i. For Zone, select External.
j. For Device, select Modem .
This should bethe same modem selected for the WWAN_PublicWWAN.
k. Enable APN list only.
l. Click to expand APN list > APN.

Digi IX20 Specifications

General

Category	Wireless Router
Cellular Connectivity	4G LTE
Ethernet Ports	4
Wi-Fi	802.11ac
SIM Slots	2
WAN Ports	1
LAN Ports	3
Weight	0.5 kg
Operating Temperature	-40°C to +70°C (-40°F to +158°F)
