Digi IX20 User Manual

Interfaces WideArea Networks(WANs)
IX20 User Guide
143
m. For APN, typethe private APNprovided to you by your cellular carrier.
5. Create the routing policies. For example, to route all traffic from LAN1 through the public APN,
and LAN2 through the private APN:
a. Click Network >Routes> Policy-based routing.
b. Click the  to add a new route policy.
c. For Label, enter Route through public APN.
d. For Interface, select Interface: WWAN_Public.
e. Configure the source address:
i. Click to expand Source address.
ii. For Type, select Interface.
iii. For Interface, select LAN1.
f. Configure the destination address:
i. Click to expand Destination address.
ii. For Type, select Interface.

Digi IX20 Specifications

General

Category	Wireless Router
Cellular Connectivity	4G LTE
Ethernet Ports	4
Wi-Fi	802.11ac
SIM Slots	2
WAN Ports	1
LAN Ports	3
Weight	0.5 kg
Operating Temperature	-40°C to +70°C (-40°F to +158°F)
